RF CABLE ASSEMBLY with FAKRA connector

  • RF CABLE ASSEMBLY with FAKRA connector
  • RF CABLE ASSEMBLY with FAKRA connector
  • RF CABLE ASSEMBLY with FAKRA connector
  • RF CABLE ASSEMBLY with FAKRA connector
  • RF CABLE ASSEMBLY with FAKRA connector
  • RF CABLE ASSEMBLY with FAKRA connector
Model No.︰FAKAR(C)F-(D)F
Brand Name︰AIE
Country of Origin︰China
Unit Price︰US $ 0.8 / PCS
Minimum Order︰1 PCS
Share on:

 Total 18 Related Items
Prev45678Next

Product Description

Model                AIE-FAKRA(C)F-(D)F
Frequency Range      DC to 6GHz
Connector 1          Blue male

Connector 2          Blordeaux-violte male
Application          GPS/GSM
Cable type           RF1.13/RG178/RG316/RG174
Cable length         100mm(According to customer customize)
Impedance            50ohms
Temperature          -40℃ to +85℃
Rated Voltage        AC 60V
Contact Resistance    20m ohm max-signal and ground
Withstand Voltage    AC 200V
Insulation Resistance    500M ohm minimum/DC 100V
VSWR                  <1.5:1

Price Terms︰EX-WORK
Payment Terms︰TT/WU/PAYPAL
Packing︰1000PCS/CARTON
Lead Time︰5-7 days after payment
